The product is mainly applied in construction site, power, communication, airport, conference and exhibition center, etc. Good stability and reliability. CE certified.
1. Moving type: manual push.
2. The platform can be extended horizontally.
3. The elevating of platform will be restricted, when charged.
4. Two settings for controlling up and down.
5. Emergency down-valve device.
Specifications of JCPT Scissors Access Aerial Work Platform:
Model No. | JCPT8 | JCPT9.5 | JCPT11.5 | |
---|---|---|---|---|
Max. Platform Height | mm | 8000 | 9500 | 11500 |
Max. Machine Height | 9090 | 10590 | 12590 | |
Min. Platform Height | 1335 | 1460 | ||
Ground Clearance | 200 | |||
Lift Rated Capacity | kg | 550 | 500 | 450 |
Platform Extend Capacity | 112 | 100 | 100 | |
Platform Size | mm | 2506×1120×1220 | ||
Platform Extend Length | 1270 | |||
Outspread Size | 2200×2780 | |||
Tyre Size | ф530×150 | |||
Lifting Motor | v/kw | 3/24 | ||
Battery | v/Ah | 2×12/120 | ||
Charger | v/A | 2024-12-20 | ||
Overall Length | mm | 2780 | ||
Overall Width | 1350 | |||
Overall Height | 2425 | 2550 | ||
Overall Net Weight | kg | 2080 | 2090 | 2200 |
