Simple and Easy Operation; Lifting movement via collapsible foot pedal; Sensitive lowering through sinking valve; Hand push drive;Overload protection via pressure valve.
Safe Operation and secure Working Conditions;Stable chassis with 2 frame rollers and 2 steering rollers.
Long Service Lift;Robust construction;Hard chromium plated frame;Hardened chromium plated ram.
Effortless Movement;Ball bearing rollers;Polyurethane rollers.
SPECIFICATIONS:
1) Rated capacity (kg): 1500, 2000, 2500, 3000, 5000.
2) Lifting height (mm): 80-200mm, 65-165mm, 73-175mm, 75-185mm.
3) Option: Variety size of Polyurethane, Nylon and Rubber wheel, Single or Tandem wheel.
4) Stainless steel or Galvanized type.
Specifications of NP25 Hand Pallet Truck:
| Model | Capacity | Fork Width | Fork Length | Min. Height | Max. Height | Steer wheel | Load Wheel | Weight |
| kg/lbs | mm/inch | mm/inch | mm/inch | mm/inch | (mm) | (mm) | kg/lbs | |
| W1 | L1 | H2 | H1 | A | B | |||
|---|---|---|---|---|---|---|---|---|
| NP15-48 | 1500/3300 | 460/18" | 810/32" | 80/3.15" | 200/7.9" | φ180*62 | φ78*100 (single) | 66/145 |
| NP15-49 | 460/18" | 980/38.5" | 70/154 | |||||
| NP15-58 | 520/20.5" | 810/32" | 66/145 | |||||
| NP15-59 | 520/20.5" | 980/38.5" | 70/154 | |||||
| NP15-510 | 520/20.5" | 1070/42" | 71/156 | |||||
| NP15-511 | 520/20.5" | 1150/43.3" | 73/160 | |||||
| NP15-610 | 600/23.5" | 1070/42" | 77/169 | |||||
| NP15-76 | 685/48" | 650/25.6" | 68/149 | |||||
| NP15-710 | 685/27" | 1070/42" | 76/167 | |||||
| NP15-712 | 685/27" | 1220/48" | 79/173 | |||||
| NP25-58 | 2500/5500 | 520/20.5" | 810/32" | 80/3.15" | 200/7.9" | φ180*62 | φ78*100 (single) or φ78*70 (tandem) | 67/147 |
| NP25-59 | 685/27" | 980/38.5" | 71/156 | |||||
| NP25-510 | 685/27" | 1070/42" | 72/158 | |||||
| NP25-511 | 520/20.5" | 1150/43.3" | 75/165 | |||||
| NP25-712 | 685/27" | 1220/48" | 80/176 | |||||
| NP30-510 | 3000/6600 | 520/20.5" | 1070/42" | 80/3.15" | 200/7.9" | φ180*62 | φ78*100 (single) or φ78*70 (tandem) | 84/184 |
| NP30-511 | 520/20.5" | 1150/43.3" | 90/198 | |||||
| NP30-712 | 685/27" | 1220/48" | 100/220 |
Remark:
1.2000kg/4400lbs, 3500kg/7700lbs, 5000kg/11000lbs capacity are also available.
2. Hand brake, food brake and parking brake is optional.
3. Option: Polyurethane, Nylon or Rubber material wheels, Single load wheel or tandem load wheel.
4. Special size of width and length can be made according to customer's requirement.
5. All specifications and figures are subject to change withou notice for improvement.
